Automatic Industrial Pellet-Fired Biomass Pallet Steam Boiler Low Pressure Domestic Hot Water Residential Wood-Fired Horizontal

Short Description:

Hot sale low pressure industrial Fuel, natural gas, biomass, coal, electricity heating water boiler machine

Horizontal oil-fired and gas-fired hot water boilers are high-efficiency thermal energy equipment featuring a horizontal internal combustion three-pass full wet-back structure. Fueled by oil (diesel, heavy oil, etc.) and gas (natural gas, liquefied petroleum gas, biogas, etc.), they heat water through burners to deliver stable high-temperature hot water. These boilers are widely used for central heating, domestic hot water supply, and industrial process heating in scenarios such as hotels, schools, hospitals, factory workshops, residential communities, bath centers, and breeding farms.

Send email to us

Product Detail

Product Tags

Boiler applicable industries:

hot spring bathing, hospitals, office buildings, residential areas, dormitory buildings for winter heating, sauna steam rooms, printing and dyeing textiles, factories, offices, schools, medical and pharmaceutical, hotel catering, food processing, chemical plants, socks factory heat setting, clothing processing, industrial steam washing, farm heating and drying, etc.Welcome to consult.

Product Paramenters

Specification and model		CDZL0.7-85/60-SCI	CDZL1.4-85/60-SCI	CDZL2.1-85/60-SCI	CDZL2.8-85/60-SCI	CDZL3.5-85/60-SCI	CDZL4.2-85/60-SCI	CDZL5.6-85/60-SCI	CDZL7.0-85/60-SCI
Rated heating capacity ( Million British thermal units )		60	120	180	240	300	360	480	600
Outlet water temperature (℃)		85	85	85	85	85	85	85	85
Backwater temperature (℃)		60	60	60	60	60	60	60	60
Particle fuel consumption (Kg/h)		195	390	585	780	975	1170	1560	1950
Transport reference weight (T)		13	18	21	23	30	35	46	58
Transportation reference dimensions(MM)	Length	5000	5200	5600	6400	6600	7320	7735	8400
	Width	2000	2240	2350	2440	2500	2733	3020	3264
	Height	3000	3000	3150	3300	3500	3550	3881	4538

Product Features

1.fired, biomaAvailable in gas-fired, oil-ss-fired and electric heating types. Flexible selection based on local energy cost and environmental standards, suitable for all kinds of factories.
2.Optimized heat exchange design ensures fast steam generation, high steam dryness and stable pressure, greatly reducing energy consumption.
3.Intelligent PLC control system realizes one-key start, automatic water supply and constant pressure operation. Multiple fault alarms ensure safe and stable 24-hour continuous work.
4.Equipped with over-pressure, water shortage, flame failure, over-temperature and electric leakage protection systems to ensure long-term safe and reliable operation.
5.Pre-assembled structure for easy installation and low maintenance cost. Widely applied in food, pharmaceutical, chemical, textile, construction and heating industries.
